Prometheus and Grafana Hands-On Projects for Beginners

As modern systems become more complex and distributed, observability has become a must-have skill for anyone working in DevOps, SRE, or infrastructure engineering. At the heart of modern observability stacks are Prometheus and Grafana—two open-source tools that power real-time monitoring and visual analytics.

Prometheus collects metrics with precision and efficiency. Grafana turns those metrics into beautiful, actionable dashboards. Together, they’re used by global companies like LinkedIn, SoundCloud, and Uber to monitor everything from microservices to Kubernetes clusters.

For learners and junior engineers, the best way to master these tools is by building hands-on projects. In this guide, we’ll walk you through beginner-friendly projects that help you understand the power of Prometheus and Grafana—while preparing you for real-world observability tasks.

What Are Prometheus and Grafana?

Prometheus: Metrics Collection and Alerting

Prometheus is a time-series database that scrapes metrics from configured targets (like servers, containers, and apps) and stores them using a high-performance storage engine. It also supports querying with its PromQL language and alerting with built-in rule evaluation.

Key Features:

• Pull-based metrics scraping via HTTP

• Support for custom exporters (Node Exporter, Blackbox Exporter, etc.)

• PromQL for querying time-series data

• AlertManager integration for notification routing

Grafana: Interactive Visualization

Grafana connects to Prometheus and other data sources to visualize data on interactive dashboards. It’s flexible, extensible, and ideal for real-time analytics and alerting.

Key Features:

• Customizable dashboards and panels

• Annotations for incidents and events

• Alerting with thresholds and rules

• Support for multiple data sources (including Prometheus, Loki, InfluxDB)

Tools and Environment Setup

Before jumping into projects, you’ll need to set up your local environment.

Minimum Requirements:

• Docker and Docker Compose (recommended for isolated environments)

• A Linux or macOS machine (Windows with WSL also works)

• Basic familiarity with YAML and the terminal

Optional Enhancements:

• Visual Studio Code with Docker and YAML plugins

• Git for version control and configuration tracking

Project 1: Monitor Your Local System with Node Exporter

Goal: Use Prometheus and Grafana to monitor CPU, memory, and disk usage of your local machine.

Steps:

1. Install Node Exporter
   Use Docker to run Node Exporter:

   arduino

   CopyEdit

   docker run -d -p 9100:9100 prom/node-exporter

2. Configure Prometheus to Scrape Node Exporter
   Create a prometheus.yml file:

   yaml

   CopyEdit

   scrape_configs: - job_name: 'node' static_configs: - targets: ['localhost:9100']

3. Start Prometheus with Docker:

   bash

   CopyEdit

   docker run -d -p 9090:9090 -v $(pwd)/prometheus.yml:/etc/prometheus/prometheus.yml prom/prometheus

4. Launch Grafana and connect to Prometheus as a data source:

   arduino

   CopyEdit

   docker run -d -p 3000:3000 grafana/grafana

5. Import a System Monitoring Dashboard from Grafana’s dashboard library (e.g., ID 1860)

What You Learn:

• How exporters work

• How to query Prometheus with PromQL

• How to visualize system metrics in Grafana

Project 2: Build a Custom Application Metrics Dashboard

Goal: Instrument a Python or Node.js app to expose custom metrics and monitor them with Prometheus and Grafana.

Steps:

1. Instrument Your Application
   Use libraries like:

   • Python: prometheus_client

   • Node.js: prom-client

   Example (Python):

   python

   CopyEdit

   from prometheus_client import start_http_server, Summary import random, time REQUEST_TIME = Summary('request_processing_seconds', 'Time spent processing request') @REQUEST_TIME.time() def process_request(): time.sleep(random.random()) if __name__ == '__main__': start_http_server(8000) while True: process_request()

2. Update Prometheus Config to scrape your app:

   yaml

   CopyEdit

   - job_name: 'custom-app' static_configs: - targets: ['host.docker.internal:8000']

3. Create a Custom Dashboard in Grafana
   Add panels for:

   • request_processing_seconds_count

   • request_processing_seconds_sum

   • Calculate averages using PromQL

What You Learn:

• How to expose application-level metrics

• PromQL basics for analyzing latency and throughput

• Customizing dashboards and alerts

Project 3: Website Uptime Monitoring with Blackbox Exporter

Goal: Use Prometheus and Grafana to monitor the availability of a public website.

Steps:

1. Run Blackbox Exporter:

   arduino

   CopyEdit

   docker run -d -p 9115:9115 prom/blackbox-exporter

2. Configure Prometheus to use the exporter:

   yaml

   CopyEdit

   - job_name: 'blackbox' metrics_path: /probe params: module: [http_2xx] static_configs: - targets: - https://refontelearning.com relabel_configs: - source_labels: [__address__] target_label: __param_target - source_labels: [__param_target] target_label: instance - target_label: __address__ replacement: localhost:9115

3. Create a Grafana Dashboard to visualize:

   • Probe success (probe_success)

   • Response duration (probe_duration_seconds)

   • Status code summaries

What You Learn:

• Uptime and endpoint monitoring

• Customizing scrape intervals

• Creating alerts for downtime

Project 4: Container Monitoring with cAdvisor and Docker Metrics

Goal: Monitor Docker containers using cAdvisor with Prometheus and Grafana.

Steps:

1. Run cAdvisor:

   ruby

   CopyEdit

   docker run -d \ -p 8080:8080 \ --volume=/:/rootfs:ro \ --volume=/var/run:/var/run:ro \ --volume=/sys:/sys:ro \ --volume=/var/lib/docker/:/var/lib/docker:ro \ google/cadvisor

2. Configure Prometheus to scrape cAdvisor:

   yaml

   CopyEdit

   - job_name: 'cadvisor' static_configs: - targets: ['localhost:8080']

3. Import Dashboard: Use Grafana dashboard ID 893 from Grafana.com

What You Learn:

• How to monitor container resource usage

• Understanding metrics like container CPU, memory, and I/O

• Real-time visualization of containerized workloads

Project 5: Alerting and Incident Simulation

Goal: Set up Prometheus AlertManager and simulate an alert condition.

Steps:

1. Configure Prometheus Alert Rules:

   yaml

   CopyEdit

   groups: - name: instance_down rules: - alert: InstanceDown expr: up == 0 for: 1m labels: severity: critical annotations: summary: "Instance {{ $labels.instance }} down" description: "Target {{ $labels.instance }} has been unreachable for more than 1 minute."

2. Run AlertManager:

   arduino

   CopyEdit

   docker run -d -p 9093:9093 prom/alertmanager

3. Integrate AlertManager with Prometheus and test by stopping a target

4. Add Grafana Notification Channel (email, Slack, or webhook)

What You Learn:

• How Prometheus alerting rules work

• Real-time incident response simulation

• Multi-platform alert routing

Final Thoughts: Projects That Prepare You for Real Work

Prometheus and Grafana are not just tools—they're foundational to modern DevOps, SRE, and platform engineering workflows. By completing hands-on projects like these, you not only learn how the tools work—you build practical, resume-ready experience that hiring managers look for.

Whether you're monitoring a local system or deploying dashboards in the cloud, each project reinforces key observability concepts that are transferable across tech stacks and industries. Start small, build iteratively, and keep pushing your observability skills forward.

FAQs

Do I need Kubernetes to start learning Prometheus and Grafana?

No. You can start with local Docker containers and gradually move to Kubernetes environments once you’re comfortable with the basics.

Are these tools only for DevOps roles?

Not at all. They're also useful for backend developers, platform engineers, site reliability engineers (SREs), and data engineers who need system visibility.

What programming languages do I need to know?

Basic Bash or Python is helpful for scripting and metric instrumentation, but Prometheus and Grafana themselves are language-agnostic and easy to use with exporters.

Can I use Prometheus and Grafana in a cloud environment?

Yes. All major cloud providers (AWS, Azure, GCP) support Prometheus and Grafana via managed services or open-source deployments.

What’s the best way to showcase these projects?

Publish your configurations and dashboards on GitHub, write a blog post explaining your setup, or create a walkthrough video. Recruiters and hiring managers love to see real-world implementations.
